Fluke 1577 Insulation Multimeter
All in one insulation testing and multimeter solution for professionals
Product Overview
Fluke 1577 Insulation Multimeter Price in Bangladesh
Fluke 1577 Insulation Multimeter is a professional grade electrical testing instrument, and the Fluke 1577 Insulation Multimeter Price in Bangladesh is widely searched by electricians, engineers, and industrial maintenance professionals who require a combined solution for insulation testing and electrical measurement. It is designed for high accuracy, safety, and versatility in demanding electrical environments.
This advanced device combines a digital insulation tester and a full featured True RMS multimeter in a single compact unit, making it highly efficient for troubleshooting and preventive maintenance tasks. It supports insulation resistance testing at multiple voltage levels, typically 500V and 1000V, allowing accurate evaluation of cables, motors, transformers, and industrial equipment.
The Fluke 1577 also functions as a complete multimeter, capable of measuring AC/DC voltage, resistance, continuity, and current. This dual functionality reduces the need for multiple instruments, making it a practical choice for field technicians working in electrical systems and industrial environments.
Safety is a key feature of this instrument. It includes live circuit detection that prevents insulation testing if dangerous voltage is present, and it also provides automatic discharge of capacitive voltage after testing to protect the user. These features ensure safe operation in high voltage environments, which is critical for industrial applications.
The device is built with a rugged design suitable for field use, featuring a large backlit display for clear readings in low light conditions. Its compact structure improves portability while maintaining durability for long term professional use. It is widely used in power plants, industrial maintenance, commercial electrical systems, and equipment diagnostics.
In practical applications, the Fluke 1577 helps professionals quickly identify insulation faults, verify electrical safety, and perform accurate system diagnostics. Its combination of insulation testing and multimeter functionality makes it a highly efficient tool for modern electrical work.
Overall, the Fluke 1577 Insulation Multimeter stands out as a reliable and advanced solution for professionals who need precision, safety, and multi-function capability in one instrument.
Key Features: Fluke 1577 Insulation Multimeter
- Insulation test voltages 500 V, 1000 V
- Insulation test: 0.1 MΩ to 600 MΩ
- Auto discharge of capacitive voltage
- AC/DC Voltage
- DC millivolts
- Auto power off to save battery power
- Accepts optional Fluke TPAKTM magnetic hanging system to free your hands for other work
- CAT III 1000V, CAT IV 600V measurement category
- Live circuit detection prevents insulation test if voltage > 30 V is detected for added user protection
- AC/DC milliamps
- Resistance (0.1 Ω to 50 MΩ)
- Continuity
- Three-year warranty
- Remote probe, test leads, alligator clips
- Rugged, utility hard case
- True RMS
- Large display with backlight
Specifications
Specifications: Fluke 1577 Insulation Multimeter
| Specifications | ||
| Voltage DC | Maximum voltage | 1000 V |
| Accuracy | ±(0.2%+2) | |
| Maximum resolution | 0.001 V | |
| Voltage AC | Maximum voltage | 1000 V |
| Accuracy | ±(2%+3) | |
| Maximum resolution | 0.1 mV | |
| Current DC | Maximum amps | 400 mA |
| Amps accuracy | ±(1.0%+2) | |
| Maximum resolution | 0.01 mA | |
| Current AC | Maximum amps | 400 mA |
| Amps accuracy | ±(2.0%+2)* | |
| Maximum resolution | 0.01 mA | |
| Resistance | Maximum resistance | 50 MΩ |
| Accuracy | ±(1.2%+2) | |
| maximum resolution | 0.1Ω | |
| Insulation Test | ||
| Minimum test current @ 1kΩ/V | 1 mA | |
| Test voltages | 500, 1000 V | |
| Maximum resistance per test voltage | 50 V | |
| 100 V | ||
| 250 V | ||
| 500 V | ||
| 1000 V | 600 MΩ | |
| Maximum resolution per test voltage | 50 V | 0.01 MΩ |
| 100 V | 0.01 MΩ | |
| 250 V | 0.1 MΩ | |
| 500 V | 0.1 MΩ | |
| 1000 V | 0.1 MΩ | |
| Accuracy per test voltage | 50 V | ±(3% + 5) |
| 100 V | ±(3% + 5) | |
| 250 V | ±(1.5% + 5) | |
| 500 V | ±(2.0% + 5) | |
| 1000 V | ±(2.0% + 5) | |
| Environmental Specifications | ||
| Operating temperature | –20°C to +55°C | |
| Storage temperature | -40°C to +60°C | |
| Humidity (without condensation) | 0% - 95% (10°C – 30°C) 0% - 75% (30°C – 40°C) 0% - 40% (40°C – 55°C) |
|
| Operating altitude | 2000 m | |
| Safety Specifications | ||
| Overvoltage category | Complies with ANSI/ISA 82.02.01 (61010-1) 2004, CAN/CSA-C22.2 NO. 61010-1-04, and IEC/EN 61010-1 2nd Edition for measurement CAT III 1000 V and CAT IV 600 V | |
| Agency approvals | 2000 m CAT III 1000 V, CAT IV 600 V; 3000 m CAT II 1000 V, CAT III 600 V | |
| Mechanical and General Specifications | ||
| Size | 203 x 100 x 50 mm (with holster) | |
| Weight | 624 g | |
| Warranty | 3 years | |
| Battery life alkaline | Meter use | 1000 hours |
| Insulation test use | Meter can perform at least 1000 insulation tests with fresh alkaline batteries at room temperature. These are standard tests of 1000 V into 1 MΩ with a duty cycle of 5 seconds on and 25 seconds off. | |
| IP rating | IP40 | |
