Hioki dt4261 digital multimeter
Professional True RMS digital multimeter designed for precise industrial electrical testing.
Product Overview
Hioki DT4261 Digital Multimeter Price in Bangladesh
Hioki DT4261 Digital Multimeter Price in Bangladesh is a professional-grade electrical testing instrument designed for engineers, electricians, industrial technicians, and maintenance professionals who require high accuracy and reliable performance in demanding environments. This mid-range professional digital multimeter from Hioki combines advanced measurement capabilities, rugged durability, and enhanced safety features, making it suitable for field diagnostics, industrial maintenance, and electrical system troubleshooting.
The Hioki DT4261 offers a wide range of measurement functions including AC and DC voltage measurement up to 1000V, current measurement with optional clamp probes, resistance testing, capacitance measurement, frequency measurement, diode testing, and continuity testing with an audible buzzer. These comprehensive testing functions allow technicians to diagnose electrical faults, analyze circuit behavior, and verify the performance of electrical equipment across industrial and commercial applications.
One of the key features of the DT4261 is its True RMS measurement capability, which provides accurate readings when measuring non-linear loads such as inverters, motor drives, and modern power electronics. The multimeter includes a 6000-count LCD display with a bar-graph indicator, enabling users to monitor measurement values clearly and track signal variations in real time during electrical diagnostics.
The device also includes several advanced diagnostic and convenience functions such as MAX/MIN recording, peak value display, data hold, auto hold, filter function, and auto power-save mode. With an optional wireless adapter (Z3210), measurement data can be transmitted to a smartphone or computer for analysis and reporting through compatible software, helping improve efficiency during professional inspections.
Safety is a major highlight of the Hioki DT4261 design. The multimeter complies with CAT III 1000V and CAT IV 600V safety standards, ensuring reliable protection when working with high-voltage electrical systems. It also features terminal shutters that prevent incorrect test lead insertion and an IP54 rating that provides resistance against dust and water, making it suitable for challenging industrial environments.
The DT4261 is powered by three AA batteries and can operate for approximately 130 hours of continuous use, allowing technicians to work for long periods without frequent battery replacement. Its compact dimensions and durable construction make it easy to carry and reliable for everyday professional use.
Hioki DT4261 Digital Multimeter Price in Bangladesh reflects the value of a highly accurate and durable testing instrument designed for professional electrical diagnostics. With True RMS measurement, advanced safety features, wireless data capabilities, and comprehensive testing functions, this multimeter is an excellent choice for professionals who require dependable and precise electrical measurements in industrial and field applications.
Key Features: Hioki DT4261 Digital Multimeter
- Enables high voltage measurement up to CAT III 2000 V
- - Safely measure solar installations like the mega-solar without interrupting the grid by simply connecting the DC High Voltage Probe P2000 to compatible Hioki clamp meters and digital multimeters (DMMs)
- CAT III 1000 V, CAT IV 600 V
Specifications
Specifications: Hioki DT4261 Digital Multimeter
Accuracy guaranteed: 1 year
DMM Accuracy: Due to a DMM's many ranges and functions, only the basic accuracy is indicated for reference. Please refer to the brochure for detailed accuracy information.
| DC Voltage range | 600.0 mV to 1000 V, 5 ranges, Basic accuracy: ±0.15% rdg. ±2 dgt. |
|---|---|
| AC Voltage range | 6.000 V to 1000 V, 4 ranges, Frequency characteristics: 40 Hz to 1 kHz Basic accuracy 40 Hz - 500 Hz: ±0.9% rdg. ±3 dgt. (True RMS, crest factor 3 or less) |
| DC + AC Voltage range | 6.000 V to 1000 V, 4 ranges, Frequency characteristics: DC, 40 Hz to 1 kHz Basic accuracy DC, 40 Hz - 500 Hz: ±1.0% rdg. ±13 dgt. (True RMS, crest factor 3 or less) |
| LoZ V | 600.0 V, 1 range, Frequency characteristics: DC, 40 Hz to 1 kHz Basic accuracy DC, 40 Hz - 500 Hz: ±1.0% rdg. ±13 dgt. (True RMS, crest factor 3 or less) |
| Resistance range | 600.0 Ω to 60.00 MΩ, 6 ranges, Basic accuracy: ±0.7% rdg. ±3 dgt. |
| DC Current range | 600.0 mA to 10.00 A, 3 ranges Basic accuracy: ±0.5% rdg. ±3 dgt. |
| AC Current range | 600.0 mA to 10.00 A, 3 ranges Basic accuracy 40 Hz - 500 Hz: ±1.4% rdg. ±3 dgt. (True RMS, crest factor 3 or less) Frequency characteristics: 40 Hz to 1 kHz |
| AC Current range (use with Clamp on probes) | 10.00 A to 1000 A, 7 ranges Basic accuracy 40 Hz - 500 Hz: Add the Clamp on probe accuracy to ±0.9% rdg. ±3 dgt. (True RMS, crest factor 3 or less) |
| Capacitance range | 1.000 μF to 10.00 mF, 5 ranges, Basic accuracy: ±1.9% rdg. ±5 dgt. |
| Continuity Check | Continuity threshold ON : 25 Ω, Continuity threshold OFF : 245 Ω, Response time: 0.5 ms or more |
| Diode test | Open terminal voltage: 2.0 V or less, Testing current: 0.2 mA or less, Threshold of forward voltage: 0.15 V to 1.8 V |
| Voltage frequency range | 99.99 Hz to 99.99 kHz, 4 ranges (Limited by minimum sensitivity voltage) Basic accuracy: ±0.1% rdg. ±1 dgt. |
| Current frequency range | 99.99 Hz to 9.999 kHz, 3 ranges (Limited by minimum sensitivity current) Basic accuracy: ±0.1% rdg. ±1 dgt. |
| Harmonic levels | [With Z3210 installed] Voltage/Current harmonic levels up to 30th, Content factor, Total harmonic distortion ratio *Harmonics can be displayed with our free app GENNECT Cross. |
| Other functions | Mis-insertion prevention shutters, fuse check function, user setting retention function, filter function, zero-adjustment, display value hold, auto hold, MAX/MIN value display, PEAK value display, auto-power save, USB communication (when optional Communication Package DT4900-01 is installed), wireless communication (when optional Wireless Adapter Z3210 is installed) |
| Display | Main and sub displays: 4-digits LCD, max. 6000 digits (excluding frequency measurement), bar-graph |
| Display refresh rates | 5 times/s (Capacitance measurement: 0.05 to 5 times/s, depending on measured value, Frequency: 1 to 2 times/s) |
| Power supply | LR6 (AA) alkaline batteries × 3, Continuous operating time: 130 hr. (without Z3210 installed), 70 hr. (with Z3210 installed and using wireless communications) |
| Dimensions and mass | 87 mm (3.43 in.) W × 185 mm (7.28 in.) H × 47 mm (1.85 in.) D, 480 g (16.9 oz.) (with test leads holder and batteries) |
| Included accessories | Test Lead L9300 × 1, Instruction Manual × 1, LR6 (AA) alkaline battery × 3, Operating Precautions ×1 |
